Bradley S19214SS Halo Stainless Steel Eye/Face Wash and Bowl, with Foot Activation

Bradley S19214SS Halo Stainless Steel Eye/Face Wash and Bowl, with Foot Activation, All stainless steel fixture, Stainless steel eye-face wash sprayhead with electro-polished finish, Complies with ANSI Standard Z358.1, Barrier-free design - fully accessible to people with physical disabilities, Universal identification sign and inspection tag included, Eye-Face Wash exceeds minimum water flow of 3 GPM at 30 PSI, Includes foot pedal or push handle for eyewash operation, Replaces Classic Model S19-210SS.

• All stainless steel fixture
• Stainless steel eye-face wash sprayhead with electro-polished finish

• Complies with ANSI/ISEA Standard Z358.1
• Barrier-free design - fully accessible to people with physical disabilities
• Universal identification sign and inspection tag included
• Eye-Face Wash exceeds minimum water flow of 3 GPM at 30 PSI
• Includes foot pedal or push handle for eyewash operation

• Industry's only self-draining design – The Aquaduct™

• Separate supply and waste pipes – meets plumbing requirements

• Ergonomic hand activation eye/face wash paddle – easy to reach from any direction

• Fully-assembled and factory-tested eye/face wash with hinged dust covers

Specifications
Standard Eye/Face Wash Units save space and fit easily into any work environment. Halo eye/face wash, operated by an ergonomic, highly visible push handle, provides effective wash down coverage and spray pattern. Integral strainer reduces debris in the water and also prevents clogging.

Pipe and Fittings
Piping to 1/2" NPT water supply inlet on unit. Piping to 1-1/4" NPT drain outlet for eyewash. 1-1/4" piping assembly manufactured of one of the following materials: x Type 304 corrosion resistant stainless steel

Ball Valve
½" stay-open eye and eye/face wash valve manufactured of the following materials:
x Type 316 stainless steel

Eye/Face Wash
The Halo eye/face wash system offers a high performance rinsing platform that provides rapid relief to an individual’s eyes and face that have been injured by chemicals or particulate. This system provides the most complete face wash available in the market. The eye/face wash includes an integral 5.1 gpm (19.2 Lpm) flow control, providing water at a safe velocity while maintaining its effectiveness (exceeds minimum water flow of 3.0 gpm (11.4 Lpm) at 30 psi (2.0 bar)). Eye/face wash is protected by flip open dust covers that open when product is activated. Safe, steady water flow under varying water supply conditions from 30–90 psi (2.0-6.1 bar) is assured by integral flow control in the sprayhead assembly. Sprayheads are made from durable Type 316 stainless steel with electro-polished finish.

Bowl
Bowl is constructed of Type 304 corrosion-resistant stainless steel.

Activation
Type 304 Stainless steel push handle with Type 304 stainless steel foot pedal.
