Speakman SE-697 Combination Eyewash and Drench Shower
Availability : In Stock - Usually Ships Same Business Day
✅ Powder-coated combination emergency shower & eyewash
✅ Pull rod activated stay open shower
✅ Paddle handle activated SE-580 eyewash
✅ Meets ANSI Z358.1
EYEWASH FEATURES: (SE-580)
• Yellow glass filled polypropylene with UV stabilizer bowl
• (2) aerated yellow plastic spray outlets with flip-top dust caps
• ½ in. NPT female brass, chrome plated, full flow stay-open ball valve
• Stainless steel push handle activator
• ½ in. NPT female inlet
• 3.2 gpm @ 30 psi
• Universal Emergency Sign Included
SHOWER FEATURES:
• 8 in. yellow plastic showerhead
• Internal 20 gpm restrictor flow control
• 1 in. NPT female brass, chrome plated, full flow stay-open ball valve
• Powder coated yellow aluminum triangular pull rod activator
• 1¼ in. galvanized steel piping stanchion and fittings
• 1¼ in. NPT female inlet & waste
• DuraJade™ powder-coated finish on stanchion for durability and enhanced corrosion resistance.
• 20 gpm @ 30 psi
From the Manufacturer
Speakman traditional series combination emergency stations provide the highest level of performance in times of need. All traditional series combination stations feature an impeller action deluge showerhead and DuraJade powder-coated 1 1/4" galvanized steel stanchion. The SE-697 model features a stay open ball valve, allowing hands free operation once the shower has been activated and an SE-580 eyewash. The high visibility yellow pull rod, makes finding the SE-697 easy in an emergency. The SE-697 meets ANSI Z385.1 compliance.
| Product finish | DuraJade Powder Coat |
| Flow rate | 20 GPM @ 30 PSI |
| Length | 30.0" |
| Collection | Safe-T-Zone Traditional |
| Product style | Industrial |
| Number of holes | 3 |
| Spray type | 1 |
| Installation type | Floor Mounted |
| Shower function | Single Function |
| Activation type | Push Handle/Pull Rod |
| Assembly required | Yes |
| Bowl material | Plastic |
| Connection size | 1.25 IN. |
| Connection type | NPT |
| Country of origin | China |
| Diverter included | No |
| Drain included | No |
| Escutcheon included | No |
| Faucet handle style | Pull Rod and Paddle |
| Flow type | Aerated & Spray |
| For use with | Repair Part RPG05-0714 Aerated bullhorn assembly |
| Galvanized location | Pipe & Fittings |
| Handle location | Top and Side |
| Handles included | Yes |
| Integral stops | No |
| Massage feature | No |
| Material composition | Stainless Steel, Brass, Plastic & Steel |
| Number of faucet handles | 2 |
| Number of shower heads | 1 |
| Pause control | No |
| Products this item repairs | RPG05-0714 |
| Repair part | RPG05-0714 |
| Repair part for catalog | RPG05-0714 - Speakman Repair Part RPG05-0714 Aerated bullhorn assembly |
| Replacement item for | SE-697-PA |
| Rough-in valve template included | No |
| Scald guard included | No |
| Self-cleaning nozzles | No |
| Shower arm included | No |
| Shower head face diameter | 8.0 |
| Shower head shape | Round |
| Temperature limit control | No |
| Tools needed for assembly | ADJUSTABLE WRENCH;PIPE WRENCH; STRAP WRENCH; PIPE THREAD SEALANT/LOCKER |
| Valve included | Yes |
| Valve type | Ball Valve |
| Vandal resistant | No |
| Weight | 37.4 |
| Width | 14.88 |
| Sprayhead | Eyewash |
| Shower Mounting | Floor Mount |
| Eyewash Bowl Material | Plastic |
| Operation | Push Handle |
| Shower Operation | Pull Down Arm |
| Shower Head Material | Plastic |
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
