- Wall-mounted eyewash/drench hose unit
- Complies with ANSI Z358.1-2014 standards
- Dual GS-Plus™ spray heads with dust covers
- Forged brass valve with stainless steel seat
- 8' reinforced PVC hose, 275 PSI maximum
- Includes spring clip mounting bracket
- ANSI-compliant identification sign included
Guardian G5026BP with Back Flow Preventer
Application: Dual purpose eyewash/drench hose for wall mounting. Unit meets the provisions of ANSI Z358.1-2014 as both an eyewash and a drench hose. Unit may be left in the mounting bracket for use as a fixed eyewash, leaving user’s hands free. Alternatively, unit may be removed for use as a drench hose to rinse any part of user’s eyes, face or body.
Spray Head Assembly: Two GS-Plus™ spray heads mounted side-by-side. Each head has a “flip top” dust cover, internal flow control and filter to remove impurities from the water flow.
Valve: Forged brass squeeze valve activated by stainless steel lever handle. Valve has replaceable stainless steel seat for exceptional durability. Locking clip engages when handle is depressed, providing “hands free” operation. Valve stays open until locking clip is released.
Hose: 8’ reinforced PVC hose. 275 PSI maximum working pressure.
Mounting: Bracket with spring clips to hold unit on wall. Clips position spray heads and handle to face forward at all times.
Supply: 3/8" NPT male swivel-type inlet.
Sign: ANSI-compliant identification sign.
Quality Assurance: Unit is completely assembled and water tested prior to shipment.
BP: In-line dual check backflow preventer installed on inlet of hose. Note: Check with code authority for compliance with local plumbing code.
| Item | Eyewash Repair Parts |
| Installation Type | Plumbed |
| Environment | General Purpose |
| Mount Type | Wall |
| Coverage | Eyes |
| ActivationSqueeze Handle | ActivationSqueeze Handle |
| Spray Head Material | Plastic |
| Color | Gray |
| Number of Spray Heads | 2 |
| Inlet Pipe Size | 3/8 in |
| Inlet Pipe Thread Type | NPT |
| Inlet Pipe Gender | Male |
| Hose Length | 8 ft |
| IncludesIdentification Sign; Inspection Tag; Wall Bracket | IncludesIdentification Sign; Inspection Tag; Wall Bracket |
| Valve Material | Forged Brass |
| Maximum Flow Rate | 3.2 gpm |
| Standards | ANSI Z358.1-2014 |
| Hose Material | PVC |
| Mounting Style | Standard |
| Burst Strength | 275 psi |
| Drench Hose Valve Type | Stay-Open |
